Exporting table1 Tables • writetfl

library(writetfl)
library(table1)
#>
#> Attaching package: 'table1'
#> The following objects are masked from 'package:base':
#>
#>     units, units<-

The table1 package creates publication-ready “Table 1” summary tables commonly used in clinical and epidemiological reporting. writetfl accepts table1 objects directly in export_tfl(), preserving column labels, bold variable names, indented summary statistics, and stratification headers.

Basic usage

Pass a table1 object directly to export_tfl():

dat <- data.frame(
  age = c(45, 52, 61, 38, 55, 47, 63, 41, 58, 50),
  sex = c("Male", "Female", "Male", "Female", "Male",
          "Female", "Male", "Female", "Male", "Female")
)

tbl <- table1(~ age + sex, data = dat)

export_tfl(tbl, preview = TRUE,
  header_left = "Study Report",
  header_rule = TRUE,
  footer_rule = TRUE
)

Column labels

Use table1::label() to set variable labels. These are used as the bold row headers in the output:

label(dat$age) <- "Age (years)"
label(dat$sex) <- "Sex"

tbl <- table1(~ age + sex, data = dat)

export_tfl(tbl, preview = TRUE,
  header_left = "Labeled Variables"
)

Variable labels appear as bold row headings with the summary statistics indented beneath them.

Caption and footnote

The caption and footnote arguments to table1() are automatically extracted into writetfl’s caption and footnote zones:

tbl <- table1(~ age + sex, data = dat,
              caption = "Table 1. Baseline Demographics",
              footnote = "ITT Population (N = 10)")

export_tfl(tbl, preview = TRUE,
  header_left  = "Protocol XY-001",
  header_right = "2025-01-15",
  header_rule  = TRUE,
  footer_rule  = TRUE
)

Stratification

Use the formula interface with | to stratify by a grouping variable. Column headers show the stratum labels and sample sizes:

dat$trt <- c(rep("Treatment", 5), rep("Placebo", 5))

label(dat$age) <- "Age (years)"
label(dat$sex) <- "Sex"

tbl <- table1(~ age + sex | trt, data = dat,
              caption = "Table 1. Demographics by Treatment Group")

export_tfl(tbl, preview = TRUE,
  header_left = "Study Report",
  header_rule = TRUE,
  footer_rule = TRUE
)

The overall argument adds a combined column:

tbl <- table1(~ age + sex | trt, data = dat, overall = "Total",
              caption = "Table 1. Demographics with Overall")

export_tfl(tbl, preview = TRUE,
  header_left = "Study Report",
  header_rule = TRUE
)

Page layout

All export_tfl_page() layout arguments work with table1 tables:

tbl <- table1(~ age + sex | trt, data = dat,
              caption = "Table 1. Demographics")

export_tfl(tbl, preview = TRUE,
  header_left   = "Protocol XY-001",
  header_center = "CONFIDENTIAL",
  header_right  = "2025-01-15",
  footnote      = "Percentages based on non-missing values.",
  footer_left   = "Sponsor: Acme Corp",
  header_rule   = TRUE,
  footer_rule   = TRUE,
  gp = list(
    header  = grid::gpar(fontsize = 11, fontface = "bold"),
    caption = grid::gpar(fontsize = 9, fontface = "italic"),
    footer  = grid::gpar(fontsize = 8)
  )
)

Multiple tables

Pass a list of table1 objects to create a multi-page PDF:

tbl_age <- table1(~ age | trt, data = dat,
                  caption = "Table 1a. Age by Treatment")
tbl_sex <- table1(~ sex | trt, data = dat,
                  caption = "Table 1b. Sex by Treatment")

export_tfl(
  list(tbl_age, tbl_sex),
  preview     = TRUE,
  header_left = "Study Report",
  header_rule = TRUE,
  footer_rule = TRUE
)

Automatic pagination

When a table has too many variables to fit on a single page, export_tfl() paginates automatically. Page breaks fall between variable groups (a variable label and its summary rows are kept together).

set.seed(42)
big_dat <- data.frame(
  v01 = rnorm(50), v02 = rnorm(50), v03 = rnorm(50),
  v04 = rnorm(50), v05 = rnorm(50), v06 = rnorm(50),
  v07 = rnorm(50), v08 = rnorm(50), v09 = rnorm(50),
  v10 = rnorm(50), v11 = rnorm(50), v12 = rnorm(50)
)
for (v in names(big_dat)) label(big_dat[[v]]) <- paste("Variable", v)

big_tbl <- table1(
  ~ v01 + v02 + v03 + v04 + v05 + v06 + v07 + v08 + v09 + v10 + v11 + v12,
  data = big_dat,
  caption = "Table 2. Many Variables"
)

export_tfl(big_tbl,
  preview      = 1:2,
  pg_height    = 5,
  header_left  = "Study Report",
  header_rule  = TRUE,
  footer_rule  = TRUE
)

Preserved features

Feature	How it’s handled
Column labels (`label()`)	Bold variable-name rows in the table body
Indented summary statistics	Spaces preserved from `t1flex()` conversion
Stratification (`\\| group`)	Column headers with stratum labels and N counts
Overall column	Included when `overall` is set
Caption	Extracted to writetfl caption zone
Footnote	Extracted to writetfl footnote zone
Custom render functions	Applied before conversion; output preserved
Variable units (`units()`)	Displayed in variable labels
Row label heading	Header for the first column
CSS styles	Translated to flextable formatting via `t1flex()`
Group-aware pagination	Variable groups kept together across page breaks

How it works

Under the hood, export_tfl() uses table1::t1flex() to convert the table1 object to a flextable, then renders the flextable to a grid grob via flextable::gen_grob(). This preserves all visual formatting including bold labels, indented statistics, borders, and spanning headers.

Caption and footnote are extracted from the table1 object’s internal structure (not the flextable) to ensure they appear in writetfl’s annotation zones rather than being duplicated inside the table.
