Exporting rtables Tables to PDF • writetfl

This vignette covers export_tfl() as used with rtables VTableTree objects. For data-frame tables built with tfl_table(), see vignette("v02-tfl_table_intro"). For gt tables, see vignette("v05-gt_tables"). For figure output, see vignette("v01-figure_output").

library(writetfl)
library(rtables)
#> Loading required package: formatters
#>
#> Attaching package: 'formatters'
#> The following object is masked from 'package:base':
#>
#>     %||%
#> Loading required package: magrittr
#>
#> Attaching package: 'rtables'
#> The following object is masked from 'package:utils':
#>
#>     str
library(grid)

Basic usage

Pass a VTableTree object directly to export_tfl(). The main title, subtitles, main footer, and provenance footer are automatically extracted and placed in writetfl’s annotation zones (caption and footnote), while the table body is rendered as monospace text via toString() and wrapped in a grid textGrob.

lyt <- basic_table(
  title       = "Iris Sepal Length by Species",
  subtitles   = "Mean values",
  main_footer = "Source: Anderson (1935)."
) |>
  split_cols_by("Species") |>
  analyze("Sepal.Length", mean)

tbl <- build_table(lyt, iris)

export_tfl(tbl, preview = TRUE)

Why annotations are extracted

rtables normally renders its title, subtitles, and footers as part of the text output. When placed inside writetfl’s page layout, this would cause duplication — the annotations would appear both in the text rendering and in writetfl’s header/footer zones. To avoid this, export_tfl() extracts rtables annotations into writetfl’s annotation fields and strips them from the rtables object before rendering.

The mapping is:

rtables annotation	writetfl field
`main_title`	`caption` (first line)
`subtitles`	`caption` (subsequent lines, joined with `\n`)
`main_footer`	`footnote`
`prov_footer`	`footnote` (appended after main footer)

Adding page layout elements

All of writetfl’s page layout arguments work with rtables tables. Pass them via ... just as you would for figures.

lyt <- basic_table(
  title       = "Iris Measurements",
  main_footer = "Source: Fisher (1936)."
) |>
  split_cols_by("Species") |>
  analyze(c("Sepal.Length", "Sepal.Width"), mean)

tbl <- build_table(lyt, iris)

export_tfl(
  tbl,
  preview      = TRUE,
  header_left  = "Study Report",
  header_right = format(Sys.Date(), "%d %b %Y"),
  header_rule  = TRUE,
  footer_rule  = TRUE
)

Multiple rtables tables

Pass a list of VTableTree objects to produce a multi-page PDF with one table per page. Each table’s annotations are extracted independently.

tbl1 <- basic_table(title = "Table 1: Sepal Length") |>
  split_cols_by("Species") |>
  analyze("Sepal.Length", mean) |>
  build_table(iris)

tbl2 <- basic_table(title = "Table 2: Petal Length") |>
  split_cols_by("Species") |>
  analyze("Petal.Length", mean) |>
  build_table(iris)

export_tfl(
  list(tbl1, tbl2),
  file         = "two-tables.pdf",
  header_left  = "Appendix",
  header_rule  = TRUE
)

Automatic pagination

When an rtables table is too tall to fit on a single page, export_tfl() uses rtables’ built-in paginate_table() to split it across pages. Row group boundaries are respected — a group is never split across pages.

big_data <- data.frame(
  arm     = rep(c("Treatment", "Control"), each = 50),
  site    = rep(paste0("Site ", 1:10), each = 10),
  outcome = rnorm(100, 50, 10)
)

lyt <- basic_table(
  title       = "Subject Outcomes by Site",
  main_footer = "Source: Clinical Trial XY-001."
) |>
  split_cols_by("arm") |>
  split_rows_by("site") |>
  analyze("outcome", mean)

tbl <- build_table(lyt, big_data)

export_tfl(
  tbl,
  file         = "paginated.pdf",
  header_left  = "Study Report",
  header_rule  = TRUE,
  footer_rule  = TRUE
)

Each page carries the same caption and footnote from the original rtables object.

How pagination works

The available content height is measured (page height minus margins, headers, footers, caption, and footnote).
Content dimensions are converted to lines-per-page (lpp) and characters-per-page (cpp) using font metrics.
rtables::paginate_table() splits the table, respecting row group boundaries and rtables’ own split rules.
Each page is rendered to text via toString() and wrapped in a textGrob with monospace font.

Font control

The rendering font can be controlled via ... parameters:

export_tfl(
  tbl,
  file                 = "custom-font.pdf",
  rtables_font_family  = "Courier",
  rtables_font_size    = 10,
  rtables_lineheight   = 1.2
)

Preserved rtables features

The following rtables features are preserved through the toString() rendering pipeline:

Feature	Preserved?	Notes
`main_title`	Yes	Extracted as writetfl caption
`subtitles`	Yes	Extracted as writetfl caption
`main_footer`	Yes	Extracted as writetfl footnote
`prov_footer`	Yes	Extracted as writetfl footnote
`split_cols_by()`	Yes	Column structure rendered by toString
`split_rows_by()`	Yes	Row groups with nesting and indentation
`analyze()`	Yes	Analysis rows with formatting
`summarize_row_groups()`	Yes	Group summary rows
`add_colcounts()`	Yes	Column N counts
`append_topleft()`	Yes	Top-left corner label
`tab_fn_*()` footnotes	Yes	Referential footnotes
Section dividers	Yes	`horizontal_sep`, `section_div`
Cell formatting	Yes	All `rcell()` format strings

Column splits

lyt <- basic_table(title = "Column Split Example") |>
  split_cols_by("Species") |>
  analyze(c("Sepal.Length", "Sepal.Width", "Petal.Length", "Petal.Width"),
          mean)

tbl <- build_table(lyt, iris)
export_tfl(tbl, preview = TRUE)

Row groups with nesting

lyt <- basic_table(title = "Nested Row Groups") |>
  split_rows_by("Species") |>
  analyze(c("Sepal.Length", "Petal.Length"), mean)

tbl <- build_table(lyt, iris)
export_tfl(tbl, preview = TRUE)

Column counts

lyt <- basic_table(title = "With Column Counts") |>
  split_cols_by("Species") |>
  add_colcounts() |>
  analyze("Sepal.Length", mean)

tbl <- build_table(lyt, iris)
export_tfl(tbl, preview = TRUE)

Top-left label

lyt <- basic_table(title = "Top-Left Label") |>
  split_cols_by("Species") |>
  append_topleft("Measurement") |>
  analyze(c("Sepal.Length", "Petal.Length"), mean)

tbl <- build_table(lyt, iris)
export_tfl(tbl, preview = TRUE)
